I like the PC version that runs off a USB memory stick in an old laptop.
The Raspberry Pi seems an ideal board for some home logging.
Reading the DS18B20 temperature chip is made simple on the Raspberry Pi.
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?Plotting_DS18S20_Temperature_Readings_Using_SVG
It would be nice if the RPi could be made to start up logging on Reboot.
How do you get the readings off the Pi?
Use a Cron job to poll the DS1820 every minute and log to a file.
Maybe limit the size of the file by appending the date in a structured way.
temp_DS_YYYYMMDD.log
I had an idea of storing the samples in a simple function call in a file ending in .js and putting this file in the web server folder.
A remote webpage could include these, and is covered in my Guestbook idea is great for a simple experiment.
It is possible to run a web server on the ESP01 devices and use it to poll the DS18B20 temperature chip.
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?Function_Calls
wget can be used to get a web page.
curses can also be used.
sudo busybox httpd -p 0.0.0.0:8086 -h /home/pi/www
I changed the hostname of my raspberry pi to patrickpi
http://patrickpi:8086/
http://patrickpi.local:8086/
The Broadband router, I have has a useful frontpage
http://192.168.1.254/
cron -A super-simple way to run scripts on boot
https://learn.pimoroni.com/article/running-scripts-at-boot
crontab -e Add:
@reboot python /home/pi/Pimoroni/blinkt/examples/rainbow.py &
A way to start a web server
A Way to start a web server when the RPi boots:-
A way to start a web server using rc.local
# Howevery this already has two web servers you can use. # * busybox httpd # * python -m httpd.server 8080 & # # To get it to boot on power up set up /etc/rc.local # # scp pi@patrickpi:/etc/rc.local rc.local.txt # #================================================= #!/bin/sh -e # owned by root # chmod 755 /etc/rc.local #!/usr/bin/ env python # # You could start a webserver using:- # python -m http.server 8080 &
# log last boot time for debug purposes date > /home/pi/rclocal.txt
# log env to file for debug purposes /usr/bin/env >> /home/pi/rclocal.txt
python dhr.py
sudo nano /lib/systemd/system/dhr.service
sudo systemctl start dhr.service
sudo systemctl stop dhr.service
sudo systemctl enable dhr.service
sudo systemctl disable dhr.service
sudo nano /lib/systemd/system/dhr.service
[Unit] Description=dhrPythonScript. After=network.target
[Service] ExecStart=/usr/bin/python3 /home/pi/dhr.py Restart=always User=pi
[Install] WantedBy=multi-user.target
This will start a webserver. this can be very useful for getting files off the Raspberry Pi.
python -m http.server 8080 --directory /home/pi
sudo nano /home/ip/dhr.py
import http.server import socketserver
PORT = 8080 DIRECTORY = "/home/pi"
class Handler( http.server.SimpleHTTPRequestHandler ): def __init__(self, *args, **kwargs): super().__init__(*args, directory=DIRECTORY, **kwargs)
# Handler = http.server.SimpleHTTPRequestHandler
![[Home]](../ipstats.gif)
with socketserver.TCPServer(("", PORT), Handler ) as httpd:
print("serving at port", PORT)
httpd.serve_forever()
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?Plotting_DS18S20_Temperature_Readings_Using_SVG
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?Function_Calls
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?ESP01
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?Esp8226
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?Arduino_Based_Logger_And_SVG_Graph
I had an idea of storing the samples in a simple function call in a file ending in .js and putting this file in the web server folder.
A remote webpage could include these, and is covered in my Guestbook idea is great for a simple experiment.
A long time ago, in 2012, before the Raspberry Pi I brought one of these:-
http://www.phaedrusltd.com/index.html -
http://www.phaedrusltd.com/acatalog/Netiom_Produtcs.html
Netiom Web enabled boards. Standard Netiom Ref: Netiom-std Netiom is a stand-alone network aware Input / Output module which can be controlled over most networks including the Internet. It can be accessed from the Internet over a standard ADSL or other always on connection making remote monitoring and control a cost effective option.
You could upload a web page of your own design and read the state of switches and analogue inputs.
I uploaded this file so I could include it into my web pages and read the values.
http://www.dougrice.plus.com/dev/js2_new.cgi
ioF( "%31,analogue,%01,%02,%03,%04,"); %99
ioF( "%31,digital1,%05,%06,%07,%08,"); %99
ioF( "%31,digital2,%27,%28,%29,%30,"); %99
ioF( "%31,counts,%11,%12,%13,%14,"); %99
ioF( "%31,digital3,%41,%42,%43,%44,%47,%48,%49,%50,%51,%52,%53,%54,%55,%56,"); %99
ioF( "%31,serial,%00,%12,%13,%14"); %99
http://www.dougrice.plus.com/dev/netiom.svg included the file and try and plot them:-
< script language = "JavaScript" type = "text/javascript" src = "_http://192.168.1.22/js2.cgi" > < / script >
I do not think it was possible to get it to poll the inputs and store in a file until the unit was polled.
http://www.emacsys.com/index.html is a later version.
Using a Raspberry Pi, this can now be done.
The WiFi enabled ESP01 chips can also do this.
Somewhere you need a process that polls the sensors on a timer tick and stores the measurements.
This should happen when the user is not logged in with their laptop or smart phone.
You could use a CRON job on a RPi to poll the NETIOM board to read the state of the pins.
An Arduino could also be used and log the data to an SD Card.
http://ccgi.dougrice.plus.com/cgi-bin/wiki.pl?Arduino_Based_Logger_And_SVG_Graph
The Netiom could remotely read and set outputs but did not seem to support a regular timer tick.
At the time I was using Microchip PIC's in assembler.
http://www.dougrice.plus.com/rt004/sr3/Logger.html - A not very successful attempt to measure the performance of a solar powered light.
Some ideas. It is not that simple, but the Raspberry Pi and Arduino boards make it much simpler.
